DL6 Hybrid Driving

DL6 Hybrid Driving

DL Series lenses are not interchangeable.

HiDrive LEDs 10,200 Lumens Per Pair – Top-bin CREE LEDs driven at 8 watts each deliver a remarkably powerful beam in a beefy 9-LED square package.

Oversized TIR Optics - Perfected Hybrid Driving Beam – Our proprietary TIR optics distribute the beam of light more efficiently than traditional reflector optics, giving our driving beam unmatched distance and width from the most compact housing possible.

DataDim™ Plug-&-Play Dimming – Our signature 3-wire design uses dedicated dimming wiring for maximum reliability and plug-&-play connection to all DENALI light harnesses, DialDim, and CANsmart Controllers.

DrySeal™ Sealed Beam Construction – Our patented technique robotically seals the lens and uses internal potting at the cable entry to guarantee 100% waterproof submersible performance even when connectors are removed.

Overbuilt Not Overpriced – Our 4mm thick powder-coated steel brackets & robust heatsink enable an impressive 21grms vibration rating, while our Polycarbonate lenses are reinforced with UV hard coating.

Specifications (Single | Pair):

LED's: Cree XPL HI (8W each)

Watts: 48W | 96W

Amp Draw: 4A | 8A

Raw Lumens: 5,100 | 10,200

Beam Distance: 1000' (305m) | 1330' (406m)

Beam Width: 203' (62m) | 270' (82m)

Connector: DataDim Compatible 3-wire DT

Operating Voltage: 9-32 VDC

Pod Size: 3" x 4.5" Rectangle x 2" Deep
