Помпа пръскачка

Помпа пръскачка

SPRAYFIxx-alkali-1,5 l

Flat jet nozzle

Specification

HDPE container with scale in ml

According to application, spray pattern, slewability and foam, the following nozzles are available: adjusting and swivelling nozzle, stainless steel + adjusting nozzle with plastic adjusting nut + swivelling foam nozzle, refer to SPRAYFIxx Alkali (#38500348) nozzle kit

Seals Viton® FKM

Manual pressure build-up with combined overpressure and venting valve

With EAN bar code

Special notes

Suited for diluted alkalis (pH value 7-14)

Colour coding at container and pump head, blue

Different nozzles allow for application-specific use

UV-resistant

Technical data

Container volume max (ml): 1500

Filling volume max (ml): 1200

Colour of container: white, transparent

Temperature range (°C): +5 / +30

Operating pressure max (bar): 2,5

Height (mm): 325

Base LxB (mm): 230 x 120

Weight (kg): 0,45

Nozzle: Flat spray nozzle, 110° ABS

Spray pattern: Flat spray angle 110° at 2,5 bar

Spraying quantity (ml/min): 450

Spraying distance (m): 0,8

Colour code: blue

Material

Container: HDPE (high density polyethylene)

Seals: Viton®, FKM

Pump head: Special plastic

Valve rod + springs: stainless steel / stainless steel

Nozzle: PP (polypropylene)

PUMP SPRAYER

SPRAYFIxx-alkali-1,5 l

Flat jet nozzle

Specification

HDPE container with scale in ml

According to application, spray pattern, slewability and foam, the following nozzles are available: adjusting and swivelling nozzle, stainless steel + adjusting nozzle with plastic adjusting nut + swivelling foam nozzle, refer to SPRAYFIxx Alkali (#38500348) nozzle kit

Seals Viton® FKM

Manual pressure build-up with combined overpressure and venting valve

With EAN bar code

Special notes

Suited for diluted alkalis (pH value 7-14)

Colour coding at container and pump head, blue

Different nozzles allow for application-specific use

UV-resistant

Technical data

Container volume max (ml): 1500

Filling volume max (ml): 1200

Colour of container: white, transparent

Temperature range (°C): +5 / +30

Operating pressure max (bar): 2,5

Height (mm): 325

Base LxB (mm): 230 x 120

Weight (kg): 0,45

Nozzle: Flat spray nozzle, 110° ABS

Spray pattern: Flat spray angle 110° at 2,5 bar

Spraying quantity (ml/min): 450

Spraying distance (m): 0,8

Colour code: blue

Material

Container: HDPE (high density polyethylene)

Seals: Viton®, FKM

Pump head: Special plastic

Valve rod + springs: stainless steel / stainless steel

Nozzle: PP (polypropylene)
